MiX 2HP
Compact three channel mono mixer
Buy Assembled [70€] » Buy PCBs [20€] »
MiX is a simple three channel mono mixer with a focus on compactness. Measuring only 2 HP, it can easily fit somewhere in the rack where there is leftover unused space.
The mixer features 3 inputs and a single output. Each input has a volume/attenuation knob. Due to the circuit's simplicity, the mixer can be used both for audio and CV signals.
Interactive BOMs
DISCLAIMER: Interactive BOMs don't have all of the info on them and are only for placement reference. Please download the full BOM sheet above when assembling.
IBOM: Main PCB » IBOM: Front PCB »
Features
Slim 2 HP design
3 inputs with volume knobs for each
Low power use
Wrong polarity protection
Size: 2HP
Depth: 54mm
Power: +12V: 4mA, -12V: 4mA
